D-Link mydlink DNR-202L

42D-Link DNR-202L User Manual
Section 5: Conguration
From the Playback page, click the Open Recording button to access the View Recorded Files window and select the video recordings you would like
to review. Step-by-step instructions are on the next page.
Search Recordings
1 Date Selection Area
Select the year, month and day of the recording you wish to view. Dates
with recordings available for playback are highlighted.
2 Time Period Selection Select a Start Time and End Time for the recording you wish to view.
3 Video Preview When Enable Preview is checked, this area will display a preview.
4 Timeline
This timeline will adjust according to the level of zoom selected.
5 Available Streams This area lists the recording devices available.
6 Zoom Slider
Use the zoom slider control to zoom in and out of the timeline.
7 Available Recordings
Recordings are graphed below the timeline. Blue bars indicate an event
was recorded. Red bars indicate the camera is set to always record.
8 Selected Period
Click within the timeline to select a recording period.
4
8
5
1
2
6
3
7
