DESCRIPTION OF OPERATING SYSTEMEX35(C)/EX40(C)/EX45(C)/EX50(C)
4
-
55
4
-
54
DESCRIPTION OF OPERATING SYSTEMEX35(C)/EX40(C)/EX45(C)/EX50(C)
H11O498A
H11O496A H11O497A
TEMPERATURE CONTROL SWITCH
The desired temperature can be set
by adjusting this dial. Warm air ows
out by turning it clockwise (red), and
cool air ows out by turning it counter-
clockwise. (Blue)
The temperature control dial only con-
trols the amount of air owing through
the heater and air conditioner.
Therefore, unnecessary load can be
applied to the air conditioner if this
dial is set to the high temperature with
the A/C in operation.
Air ows out from four front vents to-
ward the driver when turning the vent
mode dial to the ( ) position.
Air ows out from four front and four
left and right vents when turning the
vent mode dial to the Bi-level ( )
position.
BI-LEVEL DEFROST
