JOYSTICK LEVER
(1) Joystick Lever
H11O475A
MID PTO LEVER (OPTIONAL)
The mid PTO is a unit used for a
lawn mower.
Set the PTO switch to the “ON” posi-
tion after selecting the mid PTO lever
for operation.
(1) MID PTO Lever
H11O476AH23O474A
This lever is used to connect the im-
plement and 3-point hitch.
(1) External Position Control Lever
EXTERNAL POSITION
CONTROL LEVER

When operating the external
position control lever, make
sure that the shift levers and
PTO shift lever are set in the
neutral position. Also, make
sure that the parking brake is
applied and the engine is idling.

Use the outer position control
lever only on a level ground.
This joystick lever is used only to lift
and lower the loader attached to the
tractor.
For detailed information, refer to
“Handling Loader” in Chapter 6.
WARNING

Engine will start with mid PTO
OFF and PTO switch OFF, shut-
tle or range shift lever is in neu-
tral position, brake pedal de-
pressed.
IMPORTANT
