SPECIFICATIONS FOR A/C
REFRIGERANT AND LUBRICANT
H11O499A
7-PIN POWER OUTPUT SOCKET
The 7-pin socket is installed on the
rear left side of the tractor.
This supplies power to the brake
lamps, turn signal lamps, and posi-
tion lamps of the trailer.
(1) Power connector
a soft brush and water carefully
not to bend it.
3. Operation in summer season:
Make sure to check the tension of
the A/C belt before using the A/C
frequently.

The A/C system is charged
with new refrigerant that does
not destroy the ozone layer. Be
careful when servicing the A/C
system.

Do not use unspecified re-
frigerant and compressor oil,
or the air conditioner system
could be seriously damaged.

The performance of the A/C
becomes poor when the refrig-
erant is insufficient. Howev-
er, charging the air condition-
er with excessive refrigerant
affects its performance nega-
tively. Therefore, have the sys-
tem checked by a KIOTI Dealer
if malfunction is found.
CAUTION

Have the air conditioner ser-
viced by a qualified service
personnel. If it is serviced by
an unqualified person, he/she
can be injured by the refriger-
ant under high pressure.
WARNING
Item
New
refrigerant
Compressor
oil
Type R-134a UCON488
Charging
amount
0.75 kg 265cc
