Daedong KIOTI EX45 - Checking Wheel Bolt;Nut TORQUE(Q); Checking Wheel Bolt;Nut Torque (Q); Adjusting Clutch Pedal(R); Adjusting Clutch Pedal (R)

7
-
21
7
-
20
MAINTENANCEEX35(C)/EX40(C)/EX45(C)/EX50(C)
7
-
21
7
-
20
MAINTENANCEEX35(C)/EX40(C)/EX45(C)/EX50(C)
H11O627A
H11O620A
(1) Clutch Pedal (2) Clutch Rod
(A) Free Play
Check wheel bolts and nuts regular-
ly especially when new. If they are
loose, tighten them as follows.



    


     
   -


     -


(1) Front Wheel Bolt/Nut
(2) Rear Wheel Bolt/Nut
Item Tightening torque
Front
wheel
Bolt
78~90N
.
m (57-67lbf
.
ft)
Nut
63~73N
.
m (46-54lbf
.
ft)
Rear
wheel
Bolt
225N
.
m (166lbf
.
ft)
Nut
225N
.
m (166lbf
.
ft)
CAUTION

M47-EU-07.indd 20 2012-03-14 오후 7:19:14
