(1) PTO Shift Lever
PTO SHIFT LEVER
To avoid personal injury:

When disassembling, assem-
bling or cleaning the PTO sy-
stem, make sure that to stop
all rotating parts and the en-
gine before disengaging the
PTO.
H11O459A
This lever is to shift the PTO speed
into 3 speeds (ROPS model).
1st 2nd 3rd
540 750 1,000
(rpm)
CAUTION
CLUTCH PEDAL
(1) Clutch Pedal
H11O460A
MANUAL Type
Make sure to depress the clutch ped-
al to its end. To start off smoothly, put
the main and range shift levers into
the proper positions and release the
clutch pedal slowly.

Never put your foot onto the
clutch pedal during driving.
The clutch disc can be worn
pre-maturely.

Be sure to depress the clutch
pedal fully when shifting. Oth-
erwise, the shift gear can be
broken.
IMPORTANT
※Note:
The other tractors except
EX40 and EX50 has only
1 speed(540 rpm) of PTO.
