H11O301a
ROPS MODEL
※A1: Overall length including weight and folded ROPS
A2: Overall length excluding weight
C1: Overall height with folded ROPS
C2: Overall height with raised ROPS
E1: Front wheel tread E2:Rear wheel tread
ITEM
MODEL
EX35(C) EX40(C) EX45(C)/50(C)
1. Overall length (A1) 3,942 (155.2) 3,942 (155.2)
2. Overall length (A2)
3,615 (142.3) 3,650 (143.7)
3. Overall length (A3)
3,280 (129.1) 3,410 (134.2)
4. Overall width (B)
1,565 (61.6) 1,625 (64.0) 1,760 (69.3)
5. Overall height (C1)
1,430 (56.3) 1,508 (59.4)
6. Overall height (C2)
2,365 (93.1) 2,415 (95.1) 2,445 (96.3)
7. Wheel base (D)
1,767 (69.5) 1,880 (74.0)
8. Tread (E1)
1,245 (49.0) 1,248 (49.1) 1,365 (53.7)
9. Tread (E2)
1,237~1,347
(48.7~53.0)
1,262~1,490
(49.7~58.6)
1,370~1,515
(53.9~59.6)
10. Ground clearance (F)
365 (14.3) 375 (14.7) 405 (15.9)
mm (in.)
※These dimensions are measured with the standard tires installed to the ROPS model tractor.
