Lubrication
2-7
Radiator
Removal/Installation
Remove the front wheel.
Remove the front cover, front side cover and
inner box.
Loosen the flange bolt(3EA), oil bolt and remove
the radiator from the main pipe bracket.
Radiator
Radiator bracket
Radiator collar
Flange bolt
bolts
Radiator
