Service Information
1-5
Item Q’ty Thread dia(mm)
Torque value
Remarks
kg.m(N.m,ft-lb)
Oil filter cap 1 20 1.5(15, 11)
Valve adjust screw lock nut 4 5 1.1(11, 8)
Kick starter pedal bolt 1 6 1.2(12, 8)
Flywheel bolt 1 12 5.5(55, 40) Apply engine oil
Drive face bolt 1 12 5.5(55, 40)
Clutch outer bolt 1 12 5.5(55, 40)
Cam chain tensioner pivot bolt 1 8 1.0(10, 7)
Spark plug 1 12 1.2(12, 9)
Cam sprocket bolt 2 6 1.2(12, 9) Apply engine oil
Camshaft holder nut 4 8 2.0(20, 14) Apply engine oil
Cam chain tensioner mounting bolt 2 6 1.2(12, 9)
Cam chain tensioner sealing screw 1 6 0.4(4, 2.9)
Cylinder head cover bolt 4 6 1.0(10, 7)
Transmission cover bolt 8 6 1.2(12, 8)
Transmission cover drain bolt 1 8 1.0(10, 7)
Transmission cover check bolt 1 8 0.9(9, 6)
Cooling fan bolt 3 6 1.0(10, 7)
Starting clutch nut 1 22 9.5(95, 67)
Starter motor terminal nut 2 6 0.9(9, 6)
Radiator hose eye joint bolt 4 12 3.2(32, 23)
Radiator hose nut 2 14 3.2(32, 23)
Torque Values
Engine
Item Q’ty Thread dia(mm)
Torque value
Remarks
kg.m(N.m,ft-lb)
Steering stem lock nut 1 26 7.5(75, 55)
Steering top thread nut 1 26 0.3(3, 2) Initial torque
Handle post nut 1 10 6.0(60, 44)
Front fork bottom bridge bolt 4 10 7.5(75, 55)
Front fork socket bolt 2 8 2.0(20, 14)
Apply locking agent
Front axle nut 1 12 5.5~6.5(55~65, 40~47)
Front brake disk bolt 3 8 3.9(39, 28)
Apply locking agent
Ignition coil bolt 1 5 0.5(5, 4)
Rear axle nut 1 14 6.0-8.0(60-80, 43-58)
Engine hanger nut 2 10 7.3(73, 53)
Engine hanger plate bolt 6 10 2.7(27, 20)
Frame
