1-6
Service Information
Item Q’ty Thread dia(mm)
Torque value
Remarks
kg.m(N.m,ft-lb)
Brake caliper bracket bolt 2 8 2.7(27, 20)
Brake caliper bleeder valve 1 8 0.6(6, 4.3)
Brake caliper slide pin (socket bolt)
18 2.3(23, 17)
Brake caliper pin bolt 1 8 1.8(18, 13)
Apply locking agent
Brake pad pin bolt 2 8 1.8(18, 13)
Master cylinder reservoir cap 4 4 0.13(1.3, 0.94)
Brake hose bolt 2 10 3.5(35, 25)
Brake lever pivot bolt 1 6 1.0(10, 7)
Brake lever pivot lock nut 1 6 1.0(10, 7)
Rear shock-absorber upper bolt 1 10 2.7(27, 20)
Rear shock-absorber lower bolt 1 10 4.0(40, 29)
Rear shock-absorber damper rod lock nut
210 3.8(38, 27)
Apply locking agent
Torque values listed above are for specific tightening points. Torque values for other items are listed in the
following table.
SH(Small Head): Indicates 6mm bolt of 8mm flange head.
Item
Torque Value
Item
Torque Value
N.m Kg-m ft-lb N-.m Kg-m ft-lb
5mm bolt, nut 5 0.5 4 5mm screw 4 0.4 3
6mm bolt, nut 10 1.0 7 6mm screw 9 0.9 7
8mm bolt, nut 22 2.2 16 6mm flange bolt, nut 9 0.9 7
10mm bolt, nut 35 3.5 25 6mm flange bolt, nut 12 1.2 9
12mm bolt, nut 55 5.5 40 8mm flange bolt, nut 27 2.7 20
10mm flange bolt, nut 40 4.0 29
