3.4.2 Keyboard Rest
The fitting procedure is as follows: -
Adjust the screw feet if fitted so that they support the keyboard rest evenly.
Note: A compact P.C. keyboard should be positioned between the emergency
stop button and the lamp on/off switch.
When the emergency stop button is pressed it will require a reset. To reset the
switch, twist and pull. If this is not performed the machine cannot be powered up.
4000HS
Ke
y
board Res
t
Connect the connectors together that supply the emergency stop
buttton and the on/off switch for the lamp. Connect the earth strap.
Install the keyboard rest using the two screws provided.
Adjustable Feet
