46
3) Holding the body still, rotate the main shaft until a grub screw is
visible down the access hole
4) Release the grub screw two turns using a 0.9mm key.
Note: Do not remove the screw
5) Unscrew the tweezer jaws from the body
Fitting is the reverse of removal
DO NOT OVER TIGHTEN SCREWS
Note: - Bump pull tweezer jaws are precision parts and quite expensive. Treat
them with care. The jaws are specifically designed for the size of the
solder ball to be tested.
Rotate
Hold
Grub screw
