Figure 5-83 Scene set (ANPR)
Step 2 Click Draw to draw a detect region and an exclude region in the image.
●
Detect region: The region that needs to be detected.
●
Exclude region: The region that does not need to be detected. Click Modify to modify
the drawn region.
Click Clear at the right side to draw the detection area again.
Step 3 Click Draw Target next to Target Filter to draw the maximum size and minimum size for
the detection target in the image.
Step 4 Congure parameters.
Table 5-23 Description of scene set parameters (ANPR)
Parameter
Description
Trac Flow Statistics
Select Trac Flow Stat , and the device detects the number of
motor vehicles and non-motor vehicles in the detection area and
generates the statistical report. If Trac Flow Stat is disabled, the
report has no statistical data.
Select OSD to display the statistical result on the preview page. To
clear the statistical result, click Clear.
OSD
Snap Mode Select the snap mode: Optimized Snap and Tripwire.
Relay-out
Select the Relay-out check box, and when alarm is triggered, the
system interacts with the linked alarm devices.
Alarm Delay
The Alarm linkage keeps running for the congured time after
alarm is ended.
Step 5 Set arming periods and alarm linkage action. For details, see "5.1.1 Alarm Linkage".
Step 6 Click Save.
Operation Manual
211
