Zoom, focus and iris: Click or to adjust zoom, focus and iris.
4.3.3.2 PTZ Function
Select the PTZ function from the drop-down list to call the corresponding functions, including Scan,
Preset, Tour, Pattern, Pan, Go to, Assistant and Light Wiper. See Figure 4-22 . For details, see Table
4-6 . Before calling PTZ function, see "4.3.2 Conguring PTZ Function" to congure PTZ function.
●
If an external PTZ is connected to the camera, the congurations are valid only when the
corresponding functions are available on the external PTZ.
●
The range of PTZ function (such as preset and tour) depends on the PTZ protocol.
Figure 4-22 PTZ function
Table 4-6 Description of PTZ function
Parameter Description
Scan
Set the scan number and click Start , the camera moves horizontally at a
certain speed between the set left and right limit. Click Stop to stop
scanning.
Preset
Set the preset number and click Go to, the camera quickly positions the
corresponding preset.
Tour
Set the tour number and click Start , the camera moves in the order of the
selected presets. Click Stop to stop touring.
Pattern
Set the pattern number and click Start , the camera moves continuously
according to the operation recording. Click Stop to stop patterning.
Operation recording includes the information of manual operation, focus
and zoom.
Pan
Click Start, and the camera rotates 360° at a certain speed in horizontal
direction.
Go to
Set the horizontal angle, vertical angle, and zoom. Click Go to to position a
certain point accurately.
Assistant
Set the assistant number and click Aux On to enable the corresponding
assistant function, and then you can adjust the camera. Click Aux O to
disable the corresponding assistant function.
Light/Wiper
Set the light or wiper of the camera.
●
Click Enable to enable light/wiper function.
●
Click Disable to disable light/wiper function.
Operation Manual
36
