User's Manual
92
Figure 3-20 Remove screws (1.5U)
Figure 3-21 Remove screws (2U)
Step 4 Match the four screw holes on the HDD with the four holes on the bracket and then fasten
the screws.
The HDD is fixed to the bracket.
Figure 3-22 Fasten screws
Step 5 see Step 4 to install other HDDs.
