Standard Specifications
●Standard Specifications
9
Standard
Specifications
M
M
Oil outlet
Plug stop
oil drain
Oil inlet
*1
Inlet oil
thermistor
*2
Discharge
thermistor
Oil
pump
*4
Electronic expansion
valve outlet thermistor
*5
Outlet oil
thermistor
Electronic expansion
valve for main circuit
Fan
Spindle of main machine
Oil tank of main machine
Condenser
*3
Condenser
thermistor
Compressor protection
thermostat
Accumulator
S2T
Filter
Room thermistor
Low-pressure gauge port
* 1
* 2
* 3
* 4
* 5
Control
board
Relief valve
(Oil)
MC
Compressor
High
pressure
switch
S3
PH
("-C" only)
Motor operated valve
for hot gas
(Refrigerant)
Evaporator
■Details of piping system
