PIM00504
No
Panel
indication
Display Display Unit Remarks
1 A*A Alarm details - Alarm details (See “13.1”)
2 A*b Power-on count
Number of
times
Power-on count at occurrence of the alarm
3 A*r
Motor speed at alarm
occurrence
10 min
−
1
Rotational speed of the motor at occurrence of
the alarm
4 A*E
Effective motor current
value
Arms
Effective current value of the motor at
occurrence of the alarm
5 A*u DC link voltage V DC link voltage at occurrence of the alarm
6 A*c Radiating fin temperature
0.1°C
Radiating fin temperature at occurrence of the
alarm
7 A*L (Reserved for the system) %
8 A*F (Reserved for the system) %
9 A*h Operation time (minutes) min
Operation time at occurrence of the alarm
10 A*H Operation time (hours) h
11 A*t
Operation time
(thousands of hours)
1000 h
* “*” represents a numeric value from 0 to 9 indicating the alarm history.
Memo
• When the power-on count exceeds 999, it is cleared to 0.
• When the rotational speed at occurrence is a negative value, three dots light.
