OUTLINE DIMENSION
INDOOR UNIT FTXC20/25/35/50
REAR
785
RIGHT
TOP VIEW
BOTTOM
INDOOR UNIT ON-OFF
SWITCH
SIGNAL RECEIVER
ROOM TEMPERATURE
THERMISTOR
LEFT
UP DOWN
FLAP
FRONT VIEW
SIDE VIEW
250
288
MODEL
NAME PLATE
INDOOR UNIT FTXC60/71
REAR
1005
RIGHT
TOP VIEW
BOTTOM
INDOOR UNIT ON-OFF
SWITCH
SIGNAL RECEIVER
ROOM TEMPERATURE
THERMISTOR
LEFT
UP DOWN
FLAP
FRONT VIEW
SIDE VIEW
288
297
MODEL
NAME
PLATE
BOTTOM
BOTTOM
REAR
REAR
All dimensions are in mm
