Si33-105 Test Operation
Test Operation R407C PLUS Series Heat Recovery System 117
Monitor Mode
Data
Mode No. LED Data Display
method
Size
(binary number)
No 1 # ! ! ! ! ! # Cool/heat group address 0 ~ 31 Lower 6 digits
No 2 # ! ! ! ! # ! Low noise / demand address 0 ~ 31 Lower 6 digits
No 3 # ! ! ! ! # # Not used
No 4 # ! ! ! # ! ! Not used 0 ~ 63 Lower 6 digits
No 5 # ! ! ! # ! # Number of connected indoor
units
0 ~ 63 units Lower 6 digits
No 6 # ! ! ! # # ! Number of connected BS units 0 ~ 63 units Lower 6 digits
No 7 # ! ! ! # # # Number of connected zone units
(excluding outdoor and BS units)
0 ~ 63 units Lower 6 digits
No 8 # ! ! # ! ! ! Number of outdoor units 0 ~ 63 units Lower 6 digits
No 9 # ! ! # ! ! # Number of BS units 0 ~ 128 units
Lower 4 digits, upper
No 10 # ! ! # ! # ! Number of BS units 0 ~ 128 units
Lower 4 digits, lower
No 11 # ! ! # ! # # Number of zone units (excluding
outdoor and BS units)
0 ~ 63 units Lower 6 digits
No 12 # ! ! # # ! ! Number of terminal blocks 0 ~ 128 units
Lower 4 digits, upper
No 13 # ! ! # # ! # Number of terminal blocks 0 ~ 128 units
Lower 4 digits, lower
No 14 # ! ! # # # ! Not used
No 15 # ! ! # # # # Not used
No 16 # ! # ! ! ! ! Not used
