Daikin R407C PLUS - Operation of the Remote Controllers Inspection; Test Operation Button

Troubleshooting by Remote Controller Si33-105
150 Troubleshooting R407C PLUS Series Heat Recovery System
2.4 Operation of The Remote Controller’s Inspection / Test
Operation Button
Inspection/test
operation
Example model
FXYCP25K
FXYFP63K
Example of capacity code display
Display
028
071
Product classification
VRV system
VRV system
VRV system
Display
1
2
F
Indoor unit system code
System classification
(VAV indoor unit)
Outdoor air intake
Standard indoor unit
Type
Wall mounted
Double flow
Corner
Multi flow
Ceiling suspended
Built-in
Floor standing
Concealed ceiling duct
Display
A
C
E
F
H
J
L
U
Indoor unit type code
Model
FXYAP
FXYCP
FXYKP
FXYFP
FXYHP
FXYSP
FXYLP
FXYMP
Type
VRV System Inverter K Series
R407C VRV PLUS Series
R407C VRV PLUS Heat recovery Series
Display
A A 1
A A 3
A 9 3
Outdoor model code
Model
RSXYP
RSXYP
RSEYP
Unit
Malfunction code
Inspection
Normal display (No display)
0
L 0
Malfunction code blinks when a malfunction occurs.
Unit
Malfunction code
Inspection
Inspection mode
Push the button.
Inspection/test
operation
Push the button.
Inspection/test
operation
Push the button.
Inspection/test
operation
Push the button.
Inspection/test
operation
Push the button.
0
L 0
Indoor unit model code display
0 7 1
F C 2
Outdoor unit model code display
– – –
A A 1
Test operation
Test operation mode
Capacity code
Indoor unit system code
Indoor unit type code
Progression code
0 7 1...
F...
C...
2...
(VF019)
