Si33-105 Characteristics
Appendix R407C PLUS Series Heat Recovery System 241
3.2 Thermistor Resistance / Temperature Characteristics
Indoor unit For air suction R1T
For liquid pipe R2T
For gas pipe R3T
Outdoor unit For outdoor air R1T
For coil R2T
For suction pipe R4T
For oil R5T
For header R6T
(k
Ω
)
T°C 0.0 0.05 T°C 0.0 0.05
-20 197.81 192.08 30 16.10 15.76
-19 186.53 181.16 31 15.43 15.10
-18 175.97 170.94 32 14.79 14.48
-17 166.07 161.36 33 14.18 13.88
-16 156.80 152.38 34 13.59 13.31
-15 148.10 143.96 35 13.04 12.77
-14 139.94 136.05 36 12.51 12.25
-13 132.28 128.63 37 12.01 11.76
-12 125.09 121.66 38 11.52 11.29
-11 118.34 115.12 39 11.06 10.84
-10 111.99 108.96 40 10.63 10.41
-9 106.03 103.18 41 10.21 10.00
-8 100.41 97.73 42 9.81 9.61
-7 95.14 92.61 43 9.42 9.24
-6 90.17 87.79 44 9.06 8.88
-5 85.49 83.25 45 8.71 8.54
-4 81.08 78.97 46 8.37 8.21
-3 76.93 74.94 47 8.05 7.90
-2 73.01 71.14 48 7.75 7.60
-1 69.32 67.56 49 7.46 7.31
0 65.84 64.17 50 7.18 7.04
1 62.54 60.96 51 6.91 6.78
2 59.43 57.94 52 6.65 6.53
3 56.49 55.08 53 6.41 6.53
4 53.71 52.38 54 6.65 6.53
5 51.09 49.83 55 6.41 6.53
6 48.61 47.42 56 6.18 6.06
7 46.26 45.14 57 5.95 5.84
8 44.05 42.98 58 5.74 5.43
9 41.95 40.94 59 5.14 5.05
10 39.96 39.01 60 4.96 4.87
11 38.08 37.18 61 4.79 4.70
12 36.30 35.45 62 4.62 4.54
13 34.62 33.81 63 4.46 4.38
14 33.02 32.25 64 4.30 4.23
15 31.50 30.77 65 4.16 4.08
16 30.06 29.37 66 4.01 3.94
17 28.70 28.05 67 3.88 3.81
18 27.41 26.78 68 3.75 3.68
19 26.18 25.59 69 3.62 3.56
20 25.01 24.45 70 3.50 3.44
21 23.91 23.37 71 3.38 3.32
22 22.85 22.35 72 3.27 3.21
23 21.85 21.37 73 3.16 3.11
24 20.90 20.45 74 3.06 3.01
25 20.00 19.56 75 2.96 2.91
26 19.14 18.73 76 2.86 2.82
27 18.32 17.93 77 2.77 2.72
28 17.54 17.17 78 2.68 2.64
29 16.80 16.45 79 2.60 2.55
30 16.10 15.76 80 2.51 2.47
