Si33-105 Specifications
Specifications R407C PLUS Series Heat Recovery System 13
1.3 Indoor Unit
Ceiling Mounted Cassette Type (Multi-flow)
Notes:
"
1 Nominal cooling capacities are based on the following conditions:
Return air temperature : 27°C DB, 19°C WB, Outdoor temperature : 35°C DB
Equivalent ref. piping : 5m (Horizontal)
"
2 Nominal heating capacities are based on the following conditions:
Return air temperature : 20°C DB, Outdoor temperature : 7°C DB, 6°C WB
Equivalent ref. piping : 5m (Horizontal)
"
3 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
Model FXYFP32KVE FXYFP40KVE FXYFP50KVE FXYFP63KVE
Power Supply
1 phase 50/60Hz
220~240V/220V
1 phase 50/60Hz
220~240V/220V
1 phase 50/60Hz
220~240V/220V
1 phase 50/60Hz
220~240V/220V
"
""
"
1 Cooling Capacity kW 3.6 4.5 5.6 7.1
"
""
"
2 Heating Capacity kW 4.0 5.0 6.3 8.0
Casing Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 230×840×840 230×840×840 230×840×840 230×840×840
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 2×8×1.5 2×8×1.5 2×8×1.5 2×8×1.5
Face Area m² 0.331 0.331 0.331 0.331
Fan
Model QTS46B14M QTS46B14M QTS46B14M QTS46B14M
Type Turbo Fan Turbo Fan Turbo Fan Turbo Fan
Motor Output × Number
of Units
W45454545
Air Flow Rate (H/L) m³/min 13/10 14/10 16/11 18/14
Drive Direct Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Sound Absorbing Thermal Insulation Material
Foamed polystyrene/
Foamed polyethyrene
Foamed polystyrene/
Foamed polyethyrene
Foamed polystyrene/
Foamed polyethyrene
Foamed polystyrene/
Foamed polyethyrene
Piping
Connections
Liquid Pipes 6.4mm (Flare Connection) 6.4mm (Flare Connection) 9.5mm (Flare Connection) 9.5mm (Flare Connection)
Gas Pipes 12.7mm (Flare Connection) 12.7mm (Flare Connection) 15.9mm (Flare Connection) 15.9mm (Flare Connection)
Drain Pipe (mm)
VP25 (External Dia. 32
Internal Dia. 25)
VP25 (External Dia. 32
Internal Dia. 25)
VP25 (External Dia. 32
Internal Dia. 25)
VP25 (External Dia. 32
Internal Dia. 25)
Weight kg 24 24 24 24
Safety Devices
Fuse
Thermal protector for Fan
Motor
Fuse
Thermal protector for Fan
Motor
Fuse
Thermal protector for Fan
Motor
Fuse
Thermal protector for Fan
Motor
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Decoration
Panels
Mode BYC125KJW1 BYC125KJW1 BYC125KJW1 BYC125KJW1
Panel Color White (10Y9/0.5) White (10Y9/0.5) White (10Y9/0.5) White (10Y9/0.5)
Dimensions: (H×W×D) mm 40×950×950 40×950×950 40×950×950 40×950×950
Air Filter
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Weight kg 5 5 5 5
Standard Accessories
Operation Manual,
Installation Manual, Paper
Pattern for Installation, Drain
Hose, Clamp metal,
Insulation for Fitting, Sealing
Pads, Clamps, Screws,
Washers.
Operation Manual,
Installation Manual, Paper
Pattern for Installation, Drain
Hose, Clamp metal,
Insulation for Fitting, Sealing
Pads, Clamps, Screws,
Washers.
Operation Manual,
Installation Manual, Paper
Pattern for Installation, Drain
Hose, Clamp metal,
Insulation for Fitting, Sealing
Pads, Clamps, Screws,
Washers.
Operation Manual,
Installation Manual, Paper
Pattern for Installation, Drain
Hose, Clamp metal,
Insulation for Fitting, Sealing
Pads, Clamps, Screws,
Washers.
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
