Daikin R407C PLUS - Page 25

Specifications Si33-105
14 Specifications R407C PLUS Series Heat Recovery System
Ceiling Mounted Cassette Type (Multi-flow)
Notes:
"
1 Nominal cooling capacities are based on the following conditions:
Return air temperature : 27°C DB, 19°C WB, Outdoor temperature : 35°C DB
Equivalent ref. piping : 5m (Horizontal)
"
2 Nominal heating capacities are based on the following conditions:
Return air temperature : 20°C DB, Outdoor temperature : 7°C DB, 6°C WB
Equivalent ref. piping : 5m (Horizontal)
"
3 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
Model FXYFP80KVE FXYFP100KVE FXYFP125KVE
Power Supply
1 phase 50/60Hz
220~240V/220V
1 phase 50/60Hz
220~240V/220V
1 phase 50/60Hz
220~240V/220V
"
""
"
1 Cooling Capacity kW 9.0 11.2 14.0
"
""
"
2 Heating Capacity kW 10.0 12.5 16.0
Casing Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 288×840×840 288×840×840 288×840×840
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 2×12×1.5 2×12×1.5 2×12×1.5
Face Area m² 0.497 0.497 0.497
Fan
Model QTS46B17M QTS46B17M QTS46B17M
Type Turbo Fan Turbo Fan Turbo Fan
Motor Output × Number
of Units
W90 90 90
Air Flow Rate (H/L) m³/min 28/20 28/21 33/24
Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Sound Absorbing Thermal Insulation Material
Foamed polystyrene/Foamed
polyethyrene
Foamed polystyrene/Foamed
polyethyrene
Foamed polystyrene/Foamed
polyethyrene
Piping
Connections
Liquid Pipes 9.5mm (Flare Connection) 9.5mm (Flare Connection) 9.5mm (Flare Connection)
Gas Pipes 15.9mm (Flare Connection) 15.9mm (Flare Connection) 19.1mm (Flare Connection)
Drain Pipe (mm)
VP25 (External Dia. 32 Internal Dia.
25)
VP25 (External Dia. 32 Internal Dia.
25)
VP25 (External Dia. 32 Internal Dia.
25)
Weight kg 28 28 28
Safety Devices
Fuse
Thermal protector for Fan Motor
Fuse
Thermal protector for Fan Motor
Fuse
Thermal protector for Fan Motor
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Decoration
Panels
Mode BYC125KJW1 BYC125KJW1 BYC125KJW1
Panel Color White (10Y9/0.5) White (10Y9/0.5) White (10Y9/0.5)
Dimensions: (H×W×D) mm 40×950×950 40×950×950 40×950×950
Air Filter
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Weight kg 5 5 5
Standard Accessories
Operation Manual, Installation
Manual, Paper Pattern for Installation,
Drain Hose, Clamp metal, Insulation
for Fitting, Sealing Pads, Clamps,
Screws, Washers.
Operation Manual, Installation
Manual, Paper Pattern for Installation,
Drain Hose, Clamp metal, Insulation
for Fitting, Sealing Pads, Clamps,
Screws, Washers.
Operation Manual, Installation
Manual, Paper Pattern for Installation,
Drain Hose, Clamp metal, Insulation
for Fitting, Sealing Pads, Clamps,
Screws, Washers.
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
