Si33-105 Specifications
Specifications R407C PLUS Series Heat Recovery System 15
Ceiling Mounted Cassette Type (Double-flow)
Notes:
!
1 Nominal cooling capacities are based on the following conditions:
Return air temperature : 27°C DB, 19°C WB, Outdoor temperature : 35°C DB
Equivalent ref. piping : 5m (Horizontal)
!
2 Nominal heating capacities are based on the following conditions:
Return air temperature : 20°C DB, Outdoor temperature : 7°C DB, 6°C WB
Equivalent ref. piping : 5m (Horizontal)
!
3 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
Model FXYCP20KV1 FXYCP25KV1 FXYCP32KV1 FXYCP40KV1
Power Supply
1 phase 50Hz
220-240V
1 phase 50Hz
220-240V
1 phase 50Hz
220-240V
1 phase 50Hz
220-240V
!
!!
!
1 Cooling Capacity kW 2.2 2.8 3.6 4.5
!
!!
!
2 Heating Capacity kW 2.5 3.2 4.0 5.0
Casing Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 305×780×600 305×780×600 305×780×600 305×995×600
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 2×10×1.5 2×10×1.5 2×10×1.5 2×10×1.5
Face Area m² 2×0.100 2×0.100 2×0.100 2×0.145
Fan
Model D17K2AA1 D17K2AB1 D17K2AB1 2D17K1AA1
Type Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan
Motor Output × Number
of Units
W10151520
Air Flow Rate (H/L) m³/min 7/5 9/6.5 9/6.5 12/9
Drive Direct Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Sound Absorbing Thermal Insulation Material Glass Wool/Urethane Foam Glass Wool/Urethane Foam Glass Wool/Urethane Foam Glass Wool/Urethane Foam
Piping
Connections
Liquid Pipes 6.4mm (Flare Connection) 6.4mm (Flare Connection) 6.4mm (Flare Connection) 6.4mm (Flare Connection)
Gas Pipes 12.7mm (Flare Connection) 12.7mm (Flare Connection) 12.7mm (Flare Connection) 12.7mm (Flare Connection)
Drain Pipe (mm)
VP25 (External Dia. 32
Internal Dia. 25)
VP25 (External Dia. 32
Internal Dia. 25)
VP25 (External Dia. 32
Internal Dia. 25)
VP25 (External Dia. 32
Internal Dia. 25)
Weight kg 26 26 26 31
Safety Devices
Fuse
Thermal Fuse for Fan Motor
Fuse
Thermal Fuse for Fan Motor
Fuse
Thermal Fuse for Fan Motor
Fuse
Thermal Fuse for Fan Motor
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Decoration
Panels
Model BYBC32GJW1 BYBC32GJW1 BYBC32GJW1 BYBC50GJW1
Panel Color White (10Y9/0.5) White (10Y9/0.5) White (10Y9/0.5) White (10Y9/0.5)
Dimensions: (H×W×D) mm 53×1,030×680 53×1,030×680 53×1,030×680 53×1,245×680
Air Filter
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Weight kg 8 8 8 8.5
Standard Accessories
Operation Manual,
Installation Manual, Paper
Pattern for Installation, Drain
Hose, Washer for Heating
Brackets, Clamp Metal,
Insulation for Fitting,
Washer Fixing Plates,
Sealing Pads, Clamps,
Screws, Washers.
Operation Manual,
Installation Manual, Paper
Pattern for Installation, Drain
Hose, Washer for Heating
Brackets, Clamp Metal,
Insulation for Fitting,
Washer Fixing Plates,
Sealing Pads, Clamps,
Screws, Washers.
Operation Manual,
Installation Manual, Paper
Pattern for Installation, Drain
Hose, Washer for Heating
Brackets, Clamp Metal,
Insulation for Fitting,
Washer Fixing Plates,
Sealing Pads, Clamps,
Screws, Washers.
Operation Manual,
Installation Manual, Paper
Pattern for Installation, Drain
Hose, Washer for Heating
Brackets, Clamp Metal,
Insulation for Fitting,
Washer Fixing Plates,
Sealing Pads, Clamps,
Screws, Washers.
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
