Daikin R407C PLUS - Model Configuration and Combination

Si33-105 Product Outline
General Information R407C PLUS Series Heat Recovery System 5
1.3 Model Configuration and Combination
1.3.1 Number of units and capacity of connectable indoor units
1.3.2 Connectable indoor unit
Indoor unit capacity
Use the above tables to determine the capacities of indoor units to be connected. Make sure the
total capacity of indoor units connected to each outdoor unit is within the specified value (kW).
!
The total capacity of connected indoor units must be within a range of 50 to 130% of the
rated capacity of the outdoor unit.
!
In some models, it is not possible to connect the maximum number of connectable indoor
units. Select models so the total capacity of connected indoor units conforms to the
specification.
Standard
series
Equivalent output 16HP 18HP 20HP 24HP
R407C VRV PLUS series system model RSEYP16KJ RSEYP18KJ RSEYP20KJ RSEYP24KJ
Outdoor unit combination Main unit REYP8KJ REYP10KJ REYP10KJ REYP16KJ
Sub unit RXEP8KJ RXEP8KJ RXEP10KJ RXEP8KJ
Total number of connectable indoor units Up to 20 units Up to 32 units
Total capacity of connectable indoor units 200~520 225~585 250~650 300~780
Standard
series
Equivalent output 26HP 28HP 30HP
R407C VRV PLUS series system model RSEYP26KJ RSEYP28KJ RSEYP30KJ
Outdoor unit combination Main unit REYP16KJ REYP20KJ REYP20KJ
Sub unit RXEP10KJ RXEP8KJ RXEP10KJ
Total number of connectable indoor units Up to 32 units
Total capacity of connectable indoor units 325~845 350~910 375~975
Indoor unit Model name
Ceiling
mounted
cassette type
Multi-flow type FXYFP32KVE·40KVE·50KVE·63KVE·80KVE·100KVE·125KVE
Double flow type
FXYCP20KV1·25KV1·32KV1·40KV1·50KV1·63KV1·80KV1·125KV1
Corner type FXYKP25KV1·32KV1·40KV1·63KV1
Ceiling mounted built-in type FXYSP20KV1·25KV1·32KV1·40KV1·50KV1·63KV1·80KV1·100KV1·125KV1
Ceiling mounted duct type FXYMP40KV1·50KV1·63KV1·80KV1·100KV1·125KV1·200KV1·250KV1
Ceiling suspended type FXYHP32KV1·63KV1·100KV1
Wall mounted type FXYAP20KV1·25KV1·32KV1·40KV1·50KV1·63KV1
Floor standing type FXYLP20KV1·25KV1·32KV1·40KV1·50KV1·63KV1
Concealed floor standing type FXYLMP20KV1·25KV1·32KV1·40KV1·50KV1·63KV1
New refrigerant model
code
P20
type
P25
type
P32
type
P40
type
P50
type
P63
type
P80
type
P100
type
P125
type
P200
type
P250
type
Selecting model capacity 2.2kW 2.8kW 3.5kW 4.5kW 5.6kW 7.0kW 9.0kW 11.2kW 14.0kW 22.4kW 28.0kW
Equivalent output 0.8HP 1HP
1.25HP
1.6HP 2.0HP 2.5HP 3.2HP 4HP 5HP 8HP 10HP
