2.2 Indoor Side
2.2.1 Indoor Unit
Parts Name
Symbol
Model
Remark
FXYFP
32KV1(VE)
FXYFP
40KV1(VE)
FXYFP
50KV1(VE)
FXYFP
63KV1(VE)
FXYFP
80KV1(VE)
FXYFP
100KV1(VE)
FXYFP
125KV1(VE)
Remote
Controller
Wired Remote
Controller
BRC1A51
Option
Wireless Remote
Controller
BRC7C512W·513W Option
Motors
Fan Motor M1F
AC 220~240V 45W 6P AC 230V 90W 6P
Thermal protector 130°C : OFF 80°C : ON
Motor for Drain Pump M1P
AC220-240V (50Hz) AC220V (60Hz)
Thermal Fuse 145°C
Swing Motor M1S
MP35HCA[3P007482-1]
Stepping Motor DC16V
Thermistors
Thermistor (Suction Air)
R1T
ST8601-1
φ
4 L250
20k
Ω
(25°C)
Thermistor (for Heat
Exchanger High Temp.)
R3T
ST8605-4
φ
8 L800
20k
Ω
(25°C)
Thermistor (Heat
Exchanger)
R2T
ST8602-4
φ
6 L800
20k
Ω
(25°C)
Others
Float Switch 33H FS-0211
Fuse F1U 250V 5A
φ
5.2
Thermal Fuse TFu 109°C 10A
Transformer T1R TR22M21R8
Parts Name Symbol
Model
Remark
FXYCP
20KV1
FXYCP
25KV1
FXYCP
32KV1
FXYCP
40KV1
FXYCP
50KV1
FXYCP
63KV1
FXYCP
80KV1
FXYCP
125KV1
Remote
Controller
Wired Remote
Controller
BRC1A51 Option
Wireless Remote
Controller
BRC7C62·67 Option
Motors
Fan Motor M1F
AC 220~240V 50Hz
1
φ
10W 1
φ
15W 1
φ
20W 1
φ
30W 1
φ
50W 1
φ
85W
Thermal Fuse 152°C
—
Thermal protector
13 5°C : O FF
87°C : ON
Motor for Drain Pump M1P
AC220-240V (50Hz)
Thermal Fuse 169°C
Swing Motor M1S
MT8-L[3PA07509-1]
AC200~240V
Thermistors
Thermistor (Suction Air)
R1T
ST8601-16
φ
4 L1250
20k
Ω
(25°C)
Thermistor (for Heat
Exchanger High Temp.)
R3T
ST8605-6
φ
8 L1250
20k
Ω
(25°C)
Thermistor (Heat
Exchanger)
R2T
ST8602-5
φ
6 L1000
20k
Ω
(25°C)
Others
Float Switch 33H FS-0211
Fuse F1U 250V 5A
φ
5.2
Transformer T1R TR22M21R8
