Product Outline Si33-105
6 General Information R407C PLUS Series Heat Recovery System
1.3.3 BS unit connection range and total indoor unit capacity allowed for
simultaneous cooling/heating operations
Model
Total capacity of connectable
indoor units
Maximum number of
connectable indoor
units
Range A
Total indoor unit capacity allowed
for connection to BS unit
BSVP100KJV1 Less than 11.2kW 3 units or less
BSVP160KJV1
11.2kW or more and less than 18.0kW
6 units or less
BSVP250KJV1 From 18.0kW to 28.0kW 8 units or less
Range B
Total indoor unit capacity allowed
for simultaneous cooling/heating
operations
RSEYP16KJY1 22.4kW or more
20 units or less
RSEYP18KJY1 25.2kW or more
RSEYP20KJY1 28.0kW or more
RSEYP24KJY1 33.6kW or more
RSEYP26KJY1 36.4kW or more
32 units or lessRSEYP28KJY1 39.2kW or more
RSEYP30KJY1 42.0kW or more
