Outline of Control (Outdoor Unit) < Symbols using in this manual > Si33-105
72 Function R407C PLUS Series Heat Recovery System
When low noise mode input (16 to 20 HP)
Note: GR/SH control: Imaginary refrigerant circulation amount/Super heat degree control
step
No.
Heat exchanger 1 Heat exchanger 2 Pressurizing
valve
Y5S
20S1 Heat
exchanger
mode
20E1 Aux.
condensor
Fan
(MF11+MF12)
20S2 Heat
exchanger
mode
20E2 Fan
(MF3+MF4)
bOFF cond 0pls OFF H+OFF OFF cond 2000pls ON+ON OFF
aOFF
cond 0pls OFF L+OFF OFF cond 2000pls ON+ON OFF
0ON evp 0pls ON
H+OFF OFF cond 2000pls ON+ON OFF
1ON evp 0pls OFF
H+OFF OFF cond 2000pls ON+ON OFF
2ON evp 0pls OFF
H+OFF OFF cond 1000pls ON+ON OFF
3ON evp 0pls OFF
H+OFF OFF cond 700pls ON+ON ON
4ON evp 0pls OFF
H+OFF OFF cond
500pls(PI)
ON+ON ON
5ON evp 0pls ON
H+OFF OFF cond 2000pls ON+OFF OFF
6ON evp 0pls ON
H+OFF OFF cond 1000pls ON+OFF OFF
7ON evp 0pls ON
H+OFF OFF cond 700pls ON+OFF ON
8ON evp 0pls ON
H+OFF OFF cond
500pls(PI)
ON+OFF ON
9ON evp 0pls OFF
H+OFF OFF cond 2000pls ON+OFF OFF
10 ON evp 0pls OFF
H+OFF OFF cond 1000pls ON+OFF OFF
11 ON evp 0pls OFF
H+OFF OFF cond 700pls ON+OFF ON
12 ON evp 0pls OFF
H+OFF OFF cond
500pls(PI)
ON+OFF ON
13 ON evp
GR/SH
control
OFF H+OFF OFF cond 2000pls ON+OFF OFF
14 ON
evp
GR/SH
control
OFF H+OFF OFF cond 1000pls ON+OFF OFF
15 ON
evp
GR/SH
control
OFF H+OFF OFF cond 700pls ON+OFF ON
16 ON
evp
GR/SH
control
OFF H+OFF OFF cond
500pls(PI)
ON+OFF ON
23 ON
evp
GR/SH
control
OFF H+OFF OFF cond 1000pls OFF+OFF OFF
24 ON
evp
GR/SH
control
OFF H+OFF ON evp 0pls OFF+OFF OFF
25 ON
evp
GR/SH
control
OFF H+OFF ON evp
SH
control
ON+OFF OFF
500pls(PI)
: Pc control
