10
AUTO · DRY · COOL · HEAT · FAN Operation
To start operation
: AUTO
: DRY
: COOL
: HEAT
: FAN
2. Press “ON/OFF button”.
• The OPERATION lamp lights up.
DRY or FAN mode AUTO or COOL or HEAT mode
The temperature setting is not variable.
2, 3
1
4
5
The air conditioner operates with the operation mode of your
choice.
From the next time on, the air conditioner will operate with the
same operation mode.
1. Press “MODE selector button” and select a
operation mode.
• Each pressing of the button advances the mode setting in
sequence.
To stop operation
3. Press “ON/OFF button” again.
• Then OPERATION lamp goes off.
To change the temperature setting
4. Press “TEMPERATURE adjustment button”.
Press “ ” to raise the temperature and press “ ” to
lower the temperature.
Set to the temperature you like.
To Next Page
