Daikin SUPER MULTI NX G Series Service Manual

SiUS12-928_B Indoor Unit
Specifications 8
1. Indoor Unit
CTXS, FTXS Series
60 Hz, 208 - 230 V
Model
CTXS07JVJU
Cooling Heating
Rated Capacity 7 kBtu/h Class
Front Panel Color White
Airflow Rate
H
cfm
(m³/min)
388 (11.0) 400 (11.3)
M 335 (9.5) 357 (10.1)
L 283 (8.0) 314 (8.9)
Fan
Type Cross Flow Fan
Motor Output W 40
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof
Running Current (Rated) A 0.18 0.2
Power Consumption (Rated) W 40 45
Power Factor (Rated) % 96.6 97.8
Temperature Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 11-7/16 × 31-5/16 × 9-3/8 (290 × 795 × 238)
Packaged Dimensions (H × W × D) in. (mm) 11 × 33-1/16 × 13-5/16 (280 × 840 × 338)
Weight (Mass) Lbs (kg) 20 (9)
Gross Weight (Gross Mass) Lbs (kg) 29 (13)
Sound Pressure
Level
H / M / L dB(A) 44 / 40 / 35 44 / 39 / 34
Heat Insulation Both Liquid and Gas Pipes
Piping Connection
Liquid in. (mm)

1/4 (

6.4)
Gas in. (mm)
3/8 ( 9.5)
Drain in. (mm)
 11/16 ( 18.0)
Drawing No. 3D066156A
Model
CTXS09HVJU CTXS12HVJU
Cooling Heating Cooling Heating
Rated Capacity 9 kBtu/h Class 12 kBtu/h Class
Front Panel Color White White
Airflow Rate
H
cfm
(m³/min)
388 (11.0) 400 (11.3) 388 (11.0) 400 (11.3)
M 335 (9.5) 357 (10.1) 335 (9.5) 357 (10.1)
L 283 (8.0) 314 (8.9) 283 (8.0) 314 (8.9)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 40
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.18 0.2 0.18 0.2
Power Consumption (Rated) W 40 45 40 45
Power Factor (Rated) % 96.6 97.8 96.6 97.8
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 11-7/16 × 31-5/16 × 9-3/8 (290 × 795 × 238) 11-7/16 × 31-5/16 × 9-3/8 (290 × 795 × 238)
Packaged Dimensions (H × W × D) in. (mm) 11 × 33-1/16 × 13-5/16 (280 × 840 × 338) 11 × 33-1/16 × 13-5/16 (280 × 840 × 338)
Weight (Mass) Lbs (kg) 20 (9) 20 (9)
Gross Weight (Gross Mass) Lbs (kg) 29 (13) 29 (13)
Sound Pressure
Level
H / M / L dB(A) 44 / 40 / 35 44 / 39 / 34 45 / 41 / 36 45 / 40 / 35
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid in. (mm)

1/4 (

6.4)

1/4 (

6.4)
Gas in. (mm)
3/8 ( 9.5) 3/8 ( 9.5)
Drain in. (mm)
 11/16 ( 18.0)  11/16 ( 18.0)
Drawing No. 3D062870A 3D062871A
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
