Daikin SUPER MULTI NX G Series Service Manual

Piping Diagrams SiUS12-928_B
269 Appendix
1. Piping Diagrams
1.1 Indoor Unit
CTXS07JVJU, CTXS09/12HVJU FTXS15/18HVJU
CTXS07LVJU, FTXS09/12LVJU FTXS15/18LVJU
INDOOR UNIT
(5/16CuT)
HEAT EXCHANGER
CROSS FLOW FAN
FIELD PIPING
(1/4CuT)
M
FAN MOTOR
FIELD PIPING
(3/8CuT)
(1/2CuT)
REFRIGERANT FLOW
COOLING
HEATING
THERMISTOR
ON HEAT EXCH.
4D048251C
(A
CuT
)
FIELD PIPING
FIELD PIPING
(
1/4CuT
)
CROSS FLOW FAN
FAN MOTOR
(
5/16CuT
)
INDOOR UNIT
(
1/2CuT
)
M
HEAT EXCHANGER
REFRIGERANT FLOW
HEATING
COOLING
5/8
1/2
A
THERMISTOR
ON HEAT EXCH.
FTXS15
FTXS18
FTXS24
4D047162A
INDOOR UNIT
1/4 CuT
HEAT EXCHANGER
CROSS FLOW FAN
FIELD PIPING
1/4 CuT
M
FAN MOTOR
FIELD PIPING
3/8 CuT
3/8 CuT
REFRIGERANT FLOW
COOLING
HEATING
4D074606
THERMISTOR
ON HEAT EXCH.
INDOOR UNIT
5/16 CuT
DISTRIBUTOR
HEAT EXCHANGER
CROSS FLOW FAN
FIELD PIPING
1/4 CuT
M
FAN MOTOR
HEADER
FIELD PIPING
1/2 CuT
1/2 CuT
REFRIGERANT FLOW
COOLING
HEATING
THERMISTOR
ON HEAT EXCH.
4D074609
