245 Removal Procedure
2.5 Removal of Coils / Thermistors
Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies
before disassembling work.
Step
Procedure Points
1. Remove the electronic
expansion valve coil.
1
Pull the electronic
expansion valve coils.
2. Remove the thermistors.
 Place the thermistor so that its
edge comes up to the edge of
the fixture.
 Be careful not to lose the clips
for the thermistors.
1
Pull out the gas pipe
thermistors.
Electronic
expansion
valve coil
(R10415)
(R17411)
Gas pipe
thermistor
(R17412)
(R6448)
Gas pipe thermistor
Clip
