Daikin SUPER MULTI NX G Series Service Manual

SiUS12-928_B Troubleshooting for Indoor Unit
Service Diagnosis 150
5.3 Fan Motor or Related Abnormality
5.3.1 DC Motor (CTXS/FTXS Series)
Remote
Controller
Display
A6
Method of
Malfunction
Detection
The rotation speed detected by the Hall IC during fan motor operation is used to determine
abnormal fan motor operation.
Malfunction
Decision
Conditions
The detected rotation speed does not reach the demanded rotation speed of the target tap, and is
less than 50% of the maximum fan motor rotation speed.
Supposed
Causes
 Layer short inside the fan motor winding
 Breaking of wire inside the fan motor
 Breaking of the fan motor lead wires
 Defective capacitor of the fan motor
 Defective indoor unit PCB
