Daikin SUPER MULTI NX G Series Service Manual

Indoor Unit SiUS12-928_B
9 Specifications
60 Hz, 230 V
60 Hz, 208 - 230 V
Model
FTXS15HVJU FTXS18HVJU
Cooling Heating Cooling Heating
Rated Capacity 15 kBtu/h Class 18 kBtu/h Class
Front Panel Color White White
Airflow Rate
H
cfm
(m³/min)
519 (14.7) 515 (14.6) 549 (15.5) 609 (17.2)
M 436 (12.3) 459 (13.0) 476 (13.5) 529 (15.0)
L 353 (10.0) 402 (11.4) 402 (11.4) 448 (12.7)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 43 43
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.18 0.18
Power Consumption (Rated) W 40 40
Power Factor (Rated) % 96.6 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 11-7/16 × 41-5/16 × 9-3/8 (290 × 1,050 × 238) 11-7/16 × 41-5/16 × 9-3/8 (290 × 1,050 × 238)
Packaged Dimensions (H × W × D) in. (mm) 13-1/4 × 45-3/16 × 14-7/16 (337 × 1,147 × 366) 13-1/4 × 45-3/16 × 14-7/16 (337 × 1,147 × 366)
Weight (Mass) Lbs (kg) 26.5 (12) 26.5 (12)
Gross Weight (Gross Mass) Lbs (kg) 38 (17) 38 (17)
Sound Pressure
Level
H / M / L dB(A) 45 / 41 / 36 44 / 40 / 35 45 / 41 / 36 44 / 40 / 35
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid in. (mm)

1/4 (

6.4)

1/4 (

6.4)
Gas in. (mm)

1/2 (

12.7)

1/2 (

12.7)
Drain in. (mm)
11/16 ( 18.0) 11/16 ( 18.0)
Drawing No. 3D062866A 3D062868A
Model
CTXS07LVJU
Cooling Heating
Rated Capacity 7 kBtu/h Class
Front Panel Color White
Airflow Rate
H
cfm
(m³/min)
332 (9.4) 350 (9.9)
M 261 (7.4) 290 (8.2)
L 194 (5.5) 233 (6.6)
SL 145 (4.1) 219 (6.2)
Fan
Type Cross Flow Fan
Motor Output W 23
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof
Running Current (Rated) A 0.09 - 0.08 0.11 - 0.10
Power Consumption (Rated) W 18 - 18 21 - 21
Power Factor (Rated) % 96.2 - 97.8 91.8 - 91.3
Temperature Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 11-5/8 × 31-1/2 × 8-7/16 (295 × 800 × 215)
Packaged Dimensions (H × W × D) in. (mm) 10-13/16 × 34-1/4 × 14-7/16 (274 × 870 × 366)
Weight (Mass) Lbs (kg) 20 (9)
Gross Weight (Gross Mass) Lbs (kg) 29 (13)
Sound Pressure
Level
H / M / L / SL dB(A) 38 / 32 / 25 / 22 38 / 33 / 28 / 25
Sound Power Level dB 54 54
Heat Insulation Both Liquid and Gas Pipes
Piping
Connections
Liquid in. (mm)

1/4 (

6.4)
Gas in. (mm)
3/8 (9.5)
Drain in. (mm)
 5/8 (16.0)
Drawing No. 3D075490
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
