Daikin SUPER MULTI NX G Series Service Manual

Indoor Unit SiUS12-928_B
11 Specifications
CDXS, FDXS Series
60 Hz, 230 V
60 Hz, 208 - 230 V
Model
FDXS09DVJU FDXS12DVJU
Cooling Heating Cooling Heating
Rated Capacity 9 kBtu/h Class 12 kBtu/h Class
External Static Pressure inAq (Pa) 0.12 (30) 0.12 (30)
Airflow Rate
H
cfm
(m³/min)
305 (8.6) 305 (8.6) 305 (8.6) 305 (8.6)
M 280 (7.9) 280 (7.9) 280 (7.9) 280 (7.9)
L 260 (7.4) 260 (7.4) 260 (7.4) 260 (7.4)
Fan
Type Sirocco Fan Sirocco Fan
Motor Output W 62 62
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.52 0.52 0.52 0.52
Power Consumption (Rated) W 72 72 72 72
Power Factor (Rated) % 60.2 60.2 60.2 60.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 7-7/8 × 27-9/16 × 24-7/16 (200 × 700 × 620) 7-7/8 × 27-9/16 × 24-7/16 (200 × 700 × 620)
Packaged Dimensions (H × W × D) in. (mm) 10-13/16 × 36-5/16 × 30-1/4 (274 × 923 × 768) 10-13/16 × 36-5/16 × 30-1/4 (274 × 923 × 768)
Weight (Mass) Lbs (kg) 47 (21) 47 (21)
Gross Weight (Gross Mass) Lbs (kg) 64 (29) 64 (29)
Sound Pressure
Level
H / M / L dB(A) 35 / 33 / 31 35 / 33 / 31 35 / 33 / 31 35 / 33 / 31
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid in. (mm)

1/4 (

6.4)

1/4 (

6.4)
Gas in. (mm)
3/8 (9.5) 3/8 (9.5)
Drain in. (mm) VP20 (O.D.  1-1/32 (
26.0), I.D. 25/32 (20.0)) VP20 (O.D.  1-1/32 (26.0), I.D. 25/32 (20.0))
Drawing No. 3D051781A 3D051782A
Model
FDXS09LVJU FDXS12LVJU
Cooling Heating Cooling Heating
Rated Capacity 9 kBtu/h Class 12 kBtu/h Class
External Static Pressure inAq (Pa) 0.12 (30) 0.12 (30)
Airflow Rate
H
cfm
(m³/min)
305 (8.6) 305 (8.6) 305 (8.6) 305 (8.6)
M 280 (7.9) 280 (7.9) 280 (7.9) 280 (7.9)
L 260 (7.4) 260 (7.4) 260 (7.4) 260 (7.4)
SL 235 (6.7) 235 (6.7) 235 (6.7) 235 (6.7)
Fan
Type Sirocco Fan Sirocco Fan
Motor Output W 62 62
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.58 - 0.52 0.58 - 0.52 0.58 - 0.52 0.58 - 0.52
Power Consumption (Rated) W 72 - 72 72 - 72 72 - 72 72 - 72
Power Factor (Rated) % 59.7 - 60.2 59.7 - 60.2 59.7 - 60.2 59.7 - 60.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 7-7/8 × 27-9/16 × 24-7/16 (200 × 700 × 620) 7-7/8 × 27-9/16 × 24-7/16 (200 × 700 × 620)
Packaged Dimensions (H × W × D) in. (mm) 10-13/16 × 36-5/16 × 30-1/4 (274 × 923 × 768) 10-13/16 × 36-5/16 × 30-1/4 (274 × 923 × 768)
Weight (Mass) Lbs (kg) 47 (21) 47 (21)
Gross Weight (Gross Mass) Lbs (kg) 64 (29) 64 (29)
Sound Pressure
Level
H / M / L dB(A) 35 / 33 / 31 35 / 33 / 31 35 / 33 / 31 35 / 33 / 31
Sound Power Level dB 51 51 51 51
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connections
Liquid in. (mm) 1/4 (6.4) 1/4 (6.4)
Gas in. (mm)  3/8 (9.5)  3/8 (9.5)
Drain in. (mm) VP20 (O.D.  1-1/32 (
26.0), I.D. 25/32 (20.0)) VP20 (O.D.  1-1/32 (26.0), I.D. 25/32 (20.0))
Drawing No. 3D075493 3D075494
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
