SiUS12-928_B Troubleshooting for Outdoor Unit
Service Diagnosis 188
Troubleshooting 24/32 class
Check No.17
Refer to P.198
Check No.19
Refer to P.199
Note: Refer to “Application of silicon grease to a power transistor and a diode bridge” on page 267 for
detail.
(R17369)
Caution
NO
Slightly dirty
NG
Too dirty
OK
NO
YES
Turn off the power and turn it on
again to start the system.
Check the radiation fin
temperature.
Check No. 17
Check the installation condition.
NO
YES
YES
Above A?
Radiation fin dirty?
Check No. 19
Check the outdoor fan or
related.
Error displayed again?
Has the PCB been
replaced?
Check if the silicon grease
(
∗
) is applied properly on
the radiation fin. If not,
apply it.
∗
Silicon grease
Part No.: 1
172698
Replace the outdoor unit
PCB.
Clean up the radiation fin.
Be sure to turn off the power switch before connecting or disconnecting
connectors, or parts may be damaged.
Replace the outdoor fan
motor.
Correct the connectors and
fan motor leads.
Replace the outdoor unit
PCB.
To Next Page
