Cabinet Configurations
www.DaikinApplied.com 13 Vertical Stack WSHP • IM 986-11
Figure 8: Single side discharge
Figure 9: Double side discharge
Figure 10: Closed plenum – field modification required
Figure 11: Side & top discharge (see Notice on page 12)
Figure 12: Double side & top discharge (see Notice on
page 12)
Figure 13: Top discharge (see Notice on page 14)
= Return Riser = Supply Riser = Drain
= Return Air = Discharge Air = Top Discharge
Note: 80" high cabinet not available with side discharge, top discharge only.
