Daikin VHF - Performance Data; PSC Motor Fan Performance

PerforManCe
Fan Performance for PSC Motor (Sizes 009 - 036)
Table 19: PSC motor CFM values
Unit Size
Rated
Airow
Speed
External Static Pressure (in-H
2
O) [Dry Coil and STD Filter) (inches of water column)
0.00 0.05 0.10 0.15 0.20 0.25 0.30 0.35 0.40
009 300
High 430 390 350 320 280 - - - -
Low 400 360 330 290 250 - - - -
012 400
High 430 390 350 320 - - - - -
Low 400 360 330 - - - - - -
015 500
High 700 700 690 670 660 640 620 590 570
Low 600 600 590 580 570 550 530 510 480
018 600
High 700 700 690 670 660 640 620 590 570
Low 600 600 590 580 570 550 530 510 480
021 700
High 880 820 780 750 720 690 650 600 520
Low 740 710 690 680 650 610 580 540 -
024 800
High 880 820 780 750 720 690 650 600 -
Low 740 710 690 680 650 610 - - -
030 1000
High 1,380 1,360 1,340 1,310 1,280 1,250 1,210 1,170 1,130
Low 1,150 1,140 1,130 1,110 1,090 1,070 1,040 1,000 960
036 1200
High 1,380 1,360 1,340 1,310 1,280 1,250 1,210 1,170 1,130
Low 1,150 1,140 1,130 1,110 1,090 1,070 1,040 1,000 960
Note: Add 0.01" ESP for the optional discharge diffuser, and 0.02" ESP for the optional return air grille.
