8 • Genie Monochrome Series Overview Genie Monochrome Series-GigE Vision Camera
Camera Performance Specifications
Specifications for each available sensor are listed after the general Genie camera specifications.
Camera Controls
Synchronization Modes Free running and Triggered
Synchronous and Reset mode
Software trigger (through Ethernet)
Exposure Modes Programmable (1µs granularity)
Pulse controlled
Trigger Input Opto-isolated, 2V to 12V typical, 2mA min.
Debounce range from 1 µs up to 255 µs
Strobe Output
Output opto-isolated: Aligned to the start of exposure with a
programmable delay, duration and polarity
Features
LUT 8-bit / 10-bit
Flip Real-time horizontal flip
Binning Horizontal (2 pixel) and Vertical (2 line)
Timestamp 1µs internal timer to timestamp images and events
Test image Internal pattern generator
User settings Select factory default or one user camera configuration
Optical Interface
Back Focal Distance—C mount 17.52 mm
Mechanical Interface
Camera Size 29(H) x 44(W) x 67(L) in mm, ( see Mechanical Specifications )
Mass < 125g (no lens)
Power connector 12 pin male Hirose
Ethernet connector RJ45
Electrical Interface
Input Voltage +11 to +13 Volts DC, ( over voltage–reverse voltage protected )
Power Dissipation < 4W
Operating Temperature 0 to 45°C
Output Data Configuration Gigabit Ethernet (IEEE 802.3)
Data and Control GigE Vision compliant at 1000 or 100 Mbps
