Dalsa Genie M640 User Manual

Genie Monochrome Series-GigE Vision Camera Genie Monochrome Series Overview • 11
Genie M640-1/3 Specifications
Item / Feature Specification
Imager Format Full frame interline CCD area scan with square pixel
Sensor Sony ICX424AL
Resolution 640 x 480 pixels
Minimum Frame Rate (free-running) 0.1 fps (one frame every 10 seconds)
Maximum Frame Rate (free-running) 64 fps
Maximum Exposure 1 / frame rate - 100μs
Pixel Size 7.4µm x 7.4µm
Pixel Format 8-bit, 10-bit
Shutter Full frame electronic shutter
Gain Range -6dB to +12dB
Genie M640-1/3 Responsivity

Dalsa Genie M640 Specifications

General

Brand	Dalsa
Model	Genie M640
Category	Security Camera
Language	English
