Genie Monochrome Series-GigE Vision Camera Genie Monochrome Series Overview • 9
Certifications
CE
EN55022, class A, Radio Disturbance Characteristics
EN61000-4-2, Electrostatic discharge immunity test
EN61000-4-3, Radiated, radio-frequency, electromagnetic field immunity test
EN61000-4-4, Electrical fast transient/burst immunity test
EN61000-4-6, Immunity to conducted disturbances, induced by radio-frequency fields
FCC
Part 15, class A
see "EC & FCC Declaration of Conformity" on page 100
RoHS
Compliancy as per European directive 2002/95/EC
(applies to camera part numbers CR-GENx-xxxxx)
Supported Industry Standards
Genie cameras are 100% compliant with the GigE Vision 1.0
specification which defines the communication interface protocol
used by any GigE Vision device. For more information see:
http://www.machinevisiononline.org/public/articles/index.cfm?cat=167
Genie cameras implement a superset of the GenICam™
specification which defines device capabilities. This description
takes the form of an XML device description file respecting the
syntax defined by the GenApi module of the GenICam™
specification. For more information see
www.genicam.org.
Genie Sensor Overview
Each sensor description below provides a specification table and response graphic. The graph describes the sensor
response to different wavelengths of light (excluding lens and light source characteristics). Visible light spans
wavelengths between about 390 - 780 nanometers. Wavelengths below 390 nm are termed ultra-violet while those
above 780 nm. are termed infra-red. The peak response is around 500 nanometers typical for each sensor model,
corresponding to a shade of blue-green.
