Dalsa Genie M640 User Manual

70 • Operational Reference Genie Monochrome Series-GigE Vision Camera
LUTFormat
(dependent on camera model)
RO ENUM Mono 8 - Unsigned = 16844800
Mono 8 - Signed = 285280256
Mono 9 - Unsigned = 16779520
Mono 9 - Signed = 285214976
Mono 10 - Unsigned = 16779776
Mono 10 - Signed = 285215232
RGB = 1124075520
TriggerSource RW ENUM Input 1 = 0
Input 2 = 1
Software = 2
OutputSelectorOutput_1 RW ENUM Open = 0
Close = 1
Strobe On: Start of Exposure = 2
Pulse On: Valid Trigger = 4
Pulse On: Invalid Trigger = 5
Pulse On: Start of Readout = 6
Pulse On: End of Readout = 7
Pulse On: End of Acquisition = 8
Pulse On: Input 1 = 9
Pulse On: Input 2 = 10
OutputSelectorOutput_2 RW ENUM Open = 0
Close = 1
Pulse On: End of Exposure = 3
Pulse On: Valid Trigger = 4
Pulse On: Invalid Trigger = 5
Pulse On: Start of Readout = 6
Pulse On: End of Readout = 7
Pulse On: End of Acquisition = 8
Pulse On: Input 1 = 9
Pulse On: Input 2 = 10
PolarityInput_1 RW ENUM Active High = 0
Active Low = 1
PolarityInput_2 RW ENUM Active High = 0
Active Low = 1
PolarityOutput_1 RW ENUM Active Close = 0
Active Open = 1
PolarityOutput_2 RW ENUM Active Close = 0
Active Open = 1
PixelFormat RW ENUM Monochrome,
8-bit = 17301505 (0x1080001)
10-bit = 17825795 (0x1100003)
Power-upConfig RW ENUM Factory Default = 0
Camera Configuration 1 = 1
SaveCameraConfigurationSelector RW ENUM Camera Configuration 1 = 1
LoadCameraConfigurationSelector RW ENUM Factory Default = 0
Camera Configuration 1 = 1
NetworkConfigurationMode RW ENUM Automatic = 0
Manual = 1
