History (Logs)
To access your AK-SM history, select the history tab.
Upto 8 datapoints can be viewed at any given time on the history
screen.
Page control
Preferences
Zoom
Save history group to le
(Creates a le that contains dened parameters.
This saves time locating the parameters when loading a graph)
Load history group
from le
Print
History Tool bar
When viewing data in the history view the tool bar has a set of
functions to enable various actions to be performed.
Convert history le to .CSV
Export history function
Export to .hst or csv le format. Saving the collected history
points (as .hst) will allow the user to re-load these at a later date
(via the ‘load history from le’ button
Load history from le
Load a saved .hst le to view
