Danfoss AK-SM 850 User Manual

Conguration -> Control -> LIGHT
Your AK-SM has the built in ability to support lighting scheules
and control via Danfoss I/O modules or via lighting panel
communications.
Typically the built in lighting control function is used to manage
general store lighting applications. The initial lighting congura-
tion is set out under the Conguration->Control page. The initial
control question asks how many lighting zones are required. The
AK-SM has the ability to share any indoor photocell congured
and to dene how many photocells are required. Once these
initial control questions have been completed the remaining
conguration is done under the Conguration->Control->Light.
Lighting control is done via built in AK-SM schedules, and the
optional use of photocells. The following section describes a
typical lighting conguration, using AK-SM control.
Detailed conguration is done under the Light
tab (Conguration->Control->Light)
The initial Lighting conguration is done
under the Conguration->Control page.
Danfoss recommends wiring any lighting circuits in
Normally Closed position. This will ensure that if
power fails to the AK-SM or I/O modules the lighting
systems will ‘fail safe’ ‘ON’
Lighting Conguration
AK-SM Built in LIGHTING control (Using AK Input / Output /
schedules & Photocells)
The following control options can be seen in the Lighting tab,
navigate and press the enter key to change / congure any
relevant points.
52 User Guide Lit. no. USCO.PI.R1.E1.02 © Danfoss 07-2013 AK-SM 850
