Danfoss FC 102 Operating Instructions

N250 N315 N400
Normal Load* NO NO NO
Typical Shaft output at 550 V [kW] 200 250 315
Typical Shaft output at 575 V [hp] 300 350 400
Typical Shaft ouTput at 690 V [kW] 250 315 400
Enclosure IP21 D2h D2h D2h
Enclosure IP54 D2h D2h D2h
Enclosure IP20 D4h D4h D4h
Output current
Continuous (at 550 V) [A] 303 360 418
Intermittent (60 s overload) (at 550 V)[A] 333 396 460
Continuous (at 575/690 V) [A] 290 344 400
Intermittent (60 s overload) (at 575/690 V) [kVA] 319 378 440
Continuous kVA (at 550 V) [kVA] 289 343 398
Continuous kVA (at 575 V) [kVA] 289 343 398
Continuous kVA (at 690 V) [kVA] 347 411 478
Max. Input current
Continuous (at 550 V) [A] 299 355 408
Continuous (at 575 V) [A] 286 339 390
Continuous (at 690 V) [A] 296 352 400
Max. cable size: mains, motor, brake and load share, mm
(AWG)
2x185 (2x350 mcm)
Max. external mains fuses [A] 400 500 550
Estimated power loss at 575 V [W] 3719 4460 5023
Estimated power loss at 690 V [W] 3848 4610 5150
Weight, enclosure IP21, IP54 kg (lbs.) 125 (275)
Weight, enclosure IP20 kg (lbs.) 125 (275)
Efficiency 0.98
Output frequency 0-590 Hz
Heatsink overtemp. trip 110 °C
Power card ambient trip 75 °C
*Normal overload=110% current for 60 s
Table 11.3 Mains Supply 3x525-690 V AC
The typical power loss is at nominal load conditions and expected to be within ±15% (tolerance relates to variety
in voltage and cable conditions).
The losses are based on the default switching frequency. The losses increase significantly at higher switching
frequencies.
The options cabinet adds weight to the frequency converter. The maximum weights of the D5h–D8h frames is
shown in Table 11.4
Frame size Description Maximum weight [kg] ([lbs.])
D5h D1h ratings+disconnect and/or brake chopper 166 (255)
D6h D1h ratings+contactor and/or circuit breaker 129 (285)
D7h D2h ratings+disconnect and/or brake chopper 200 (440)
D8h D2h ratings+contactor and/or circuit breaker 225 (496)
Table 11.4 D5h–D8h Weights
Specifications
Operating Instructions
78 Danfoss A/S © Rev. 06/2014 All rights reserved. MG16D302
