Danfoss FC 102

14-61 Function at Inverter Overload 14-62 Inv. Overload Derate Current 14-8* Options 14-80 Option Supplied by External 24VDC
14-88 Option Data Storage
14-89 Option Detection
14-9* Fault Settings 14-90 Fault Level 15-** Drive Information 15-0* Operating Data 15-00 Operating hours
15-01 Running Hours 15-02 kWh Counter
15-03 Power Up's 15-04 Over Temp's 15-05 Over Volt's 15-06 Reset kWh Counter
15-07 Reset Running Hours Counter
15-08 Number of Starts
15-1* Data Log Settings 15-10 Logging Source
15-11 Logging Interval
15-12 Trigger Event 15-13 Logging Mode 15-14 Samples Before Trigger
15-2* Historic Log 15-20 Historic Log: Event
15-21 Historic Log: Value
15-22 Historic Log: Time 15-23 Historic log: Date and Time
15-3* Alarm Log 15-30 Alarm Log: Error Code
15-31 Alarm Log: Value 15-32 Alarm Log: Time
15-33 Alarm Log: Date and Time
15-4* Drive Identication 15-40 FC Type 15-41 Power Section 15-42 Voltage 15-43 Software Version
15-44 Ordered Typecode String 15-45 Actual Typecode String
15-46 Frequency Converter Ordering No
15-47 Power Card Ordering No 15-48 LCP Id No
15-49 SW ID Control Card
15-50 SW ID Power Card 15-51 Frequency Converter Serial Number
15-53 Power Card Serial Number 15-54 Cong File Name
15-55 Vendor URL 15-56 Vendor Name
15-58 Smart Setup Filename
15-59 Filename
15-6* Option Ident 15-60 Option Mounted 15-61 Option SW Version
15-62 Option Ordering No
15-63 Option Serial No
15-64 Application Version 15-70 Option in Slot A
15-71 Slot A Option SW Version
15-72 Option in Slot B
15-73 Slot B Option SW Version
15-74 Option in Slot C0/E0
15-75 Slot C0/E0 Option SW Version 15-76 Option in Slot C1/E1 15-77 Slot C1/E1 Option SW Version
15-8* Operating Data II
15-80 Fan Running Hours
15-81 Preset Fan Running Hours
15-9* Parameter Info 15-92 Dened Parameters 15-93 Modied Parameters 15-98 Drive Identication 15-99 Parameter Metadata 16-** Data Readouts 16-0* General Status 16-00 Control Word 16-01 Reference [Unit]
16-02 Reference [%] 16-03 Status Word 16-05 Main Actual Value [%] 16-09 Custom Readout
16-1* Motor Status 16-10 Power [kW] 16-11 Power [hp] 16-12 Motor Voltage 16-13 Frequency 16-14 Motor current 16-15 Frequency [%]
16-16 Torque [Nm] 16-17 Speed [RPM]
16-18 Motor Thermal 16-20 Motor Angle
16-22 Torque [%] 16-23 Motor Shaft Power [kW]
16-24 Calibrated Stator Resistance
16-26 Power Filtered [kW] 16-27 Power Filtered [hp]
16-3* Drive Status 16-30 DC Link Voltage 16-31 System Temp. 16-32 Brake Energy /s 16-33 Brake Energy Average
16-34 Heatsink Temp. 16-35 Inverter Thermal
16-36 Inv. Nom. Current
16-37 Inv. Max. Current 16-38 SL Controller State
16-39 Control Card Temp.
16-40 Logging Buer Full 16-41 Logging Buer Full 16-43 Timed Actions Status
16-49 Current Fault Source
16-5* Ref. & Feedb. 16-50 External Reference
16-52 Feedback[Unit]
16-53 Digi Pot Reference 16-54 Feedback 1 [Unit]
16-55 Feedback 2 [Unit] 16-56 Feedback 3 [Unit]
16-58 PID Output [%]
16-59 Adjusted Setpoint
16-6* Inputs & Outputs 16-60 Digital Input 16-61 Terminal 53 Switch Setting
16-62 Analog Input 53 16-63 Terminal 54 Switch Setting
16-64 Analog Input 54
16-65 Analog Output 42 [mA] 16-66 Digital Output [bin] 16-67 Pulse Input #29 [Hz]
16-68 Pulse Input #33 [Hz]
16-69 Pulse Output #27 [Hz]
16-70 Pulse Output #29 [Hz]
16-71 Relay Output [bin]
16-72 Counter A 16-73 Counter B 16-75 Analog In X30/11 16-76 Analog In X30/12 16-77 Analog Out X30/8 [mA] 16-78 Analog Out X45/1 [mA] 16-79 Analog Out X45/3 [mA]
16-8* Fieldbus & FC Port
16-80 Fieldbus CTW 1
16-82 Fieldbus REF 1 16-84 Comm. Option STW
16-85 FC Port CTW 1 16-86 FC Port REF 1
16-9* Diagnosis Readouts 16-90 Alarm Word 16-91 Alarm Word 2
16-92 Warning Word
16-93 Warning Word 2
16-94 Ext. Status Word 16-95 Ext. Status Word 2
16-96 Maintenance Word
18-** Info & Readouts 18-0* Maintenance Log
18-00 Maintenance Log: Item
18-01 Maintenance Log: Action
18-02 Maintenance Log: Time
18-03 Maintenance Log: Date and Time
18-1* Fire Mode Log 18-10 FireMode Log:Event
18-11 Fire Mode Log: Time
18-12 Fire Mode Log: Date and Time
18-3* Inputs & Outputs 18-30 Analog Input X42/1 18-31 Analog Input X42/3 18-32 Analog Input X42/5 18-33 Analog Out X42/7 [V]
18-34 Analog Out X42/9 [V]
18-35 Analog Out X42/11 [V]
18-36 Analog Input X48/2 [mA] 18-37 Temp. Input X48/4
18-38 Temp. Input X48/7
18-39 Temp. Input X48/10
18-5* Ref. & Feedb. 18-50 Sensorless Readout [unit]
18-57 Air Pressure to Flow Air Flow
18-6* Inputs & Outputs 2 18-60 Digital Input 2 18-7* Rectier Status 18-70 Mains Voltage 18-71 Mains Frequency 18-72 Mains Imbalance 18-75 Rectier DC Volt. 20-** Drive Closed Loop 20-0* Feedback 20-00 Feedback 1 Source
20-01 Feedback 1 Conversion
20-02 Feedback 1 Source Unit
20-03 Feedback 2 Source
20-04 Feedback 2 Conversion
20-05 Feedback 2 Source Unit 20-06 Feedback 3 Source
20-07 Feedback 3 Conversion
20-08 Feedback 3 Source Unit
20-12 Reference/Feedback Unit
20-13 Minimum Reference/Feedb. 20-14 Maximum Reference/Feedb.
20-2* Feedback/Setpoint 20-20 Feedback Function 20-21 Setpoint 1 20-22 Setpoint 2 20-23 Setpoint 3 20-3* Feedb. Adv. Conv.
20-30 Refrigerant
20-31 User Dened Refrigerant A1
20-32 User Dened Refrigerant A2 20-33 User Dened Refrigerant A3
20-34 Duct 1 Area [m2]
20-35 Duct 1 Area [in2] 20-36 Duct 2 Area [m2]
20-37 Duct 2 Area [in2] 20-38 Air Density Factor [%]
20-6* Sensorless 20-60 Sensorless Unit
20-69 Sensorless Information
20-7* PID Autotuning 20-70 Closed Loop Type
20-71 PID Performance
20-72 PID Output Change
20-73 Minimum Feedback Level 20-74 Maximum Feedback Level
20-79 PID Autotuning
20-8* PID Basic Settings 20-81 PID Normal/ Inverse Control
20-82 PID Start Speed [RPM] 20-83 PID Start Speed [Hz]
20-84 On Reference Bandwidth
20-9* PID Controller 20-91 PID Anti Windup 20-93 PID Proportional Gain
20-94 PID Integral Time
20-95 PID Dierentiation Time
20-96 PID Di. Gain Limit
21-** Ext. Closed Loop 21-0* Ext. CL Autotuning 21-00 Closed Loop Type
21-01 PID Performance
21-02 PID Output Change
21-03 Minimum Feedback Level 21-04 Maximum Feedback Level
21-09 PID Autotuning
21-1* Ext. CL 1 Ref./Fb.
21-10 Ext. 1 Ref./Feedback Unit
21-11 Ext. 1 Minimum Reference
21-12 Ext. 1 Maximum Reference 21-13 Ext. 1 Reference Source
21-14 Ext. 1 Feedback Source 21-15 Ext. 1 Setpoint
21-17 Ext. 1 Reference [Unit]
21-18 Ext. 1 Feedback [Unit]
21-19 Ext. 1 Output [%]
21-2* Ext. CL 1 PID 21-20 Ext. 1 Normal/Inverse Control 21-21 Ext. 1 Proportional Gain 21-22 Ext. 1 Integral Time
21-23 Ext. 1 Dierentation Time
21-24 Ext. 1 Dif. Gain Limit
21-3* Ext. CL 2 Ref./Fb.
21-30 Ext. 2 Ref./Feedback Unit
21-31 Ext. 2 Minimum Reference
21-32 Ext. 2 Maximum Reference 21-33 Ext. 2 Reference Source
21-34 Ext. 2 Feedback Source 21-35 Ext. 2 Setpoint
21-37 Ext. 2 Reference [Unit]
21-38 Ext. 2 Feedback [Unit]
21-39 Ext. 2 Output [%]
21-4* Ext. CL 2 PID 21-40 Ext. 2 Normal/Inverse Control 21-41 Ext. 2 Proportional Gain 21-42 Ext. 2 Integral Time
21-43 Ext. 2 Dierentation Time
21-44 Ext. 2 Dif. Gain Limit
21-5* Ext. CL 3 Ref./Fb.
21-50 Ext. 3 Ref./Feedback Unit
21-51 Ext. 3 Minimum Reference
21-52 Ext. 3 Maximum Reference 21-53 Ext. 3 Reference Source
21-54 Ext. 3 Feedback Source 21-55 Ext. 3 Setpoint
21-57 Ext. 3 Reference [Unit]
21-58 Ext. 3 Feedback [Unit]
21-59 Ext. 3 Output [%]
21-6* Ext. CL 3 PID 21-60 Ext. 3 Normal/Inverse Control 21-61 Ext. 3 Proportional Gain 21-62 Ext. 3 Integral Time
21-63 Ext. 3 Dierentation Time
21-64 Ext. 3 Dif. Gain Limit
Appendix Operating Guide
MG16O102 Danfoss A/S © 01/2017 All rights reserved. 105
