22-** Appl. Functions 22-0* Miscellaneous 22-00 External Interlock Delay 22-01 Power Filter Time 22-1* Air Pres. to Flow
22-10 Air Pressure to Flow Signal source
22-11 Air Pressure to Flow Fan k-factor
22-12 Air Pressure to Flow Air density
22-13 Air Pressure to Flow Fan ow unit
22-2* No-Flow Detection 22-20 Low Power Auto Set-up
22-21 Low Power Detection
22-22 Low Speed Detection
22-23 No-Flow Function 22-24 No-Flow Delay 22-26 Dry Pump Function
22-27 Dry Pump Delay
22-3* No-Flow Power Tuning 22-30 No-Flow Power 22-31 Power Correction Factor
22-32 Low Speed [RPM]
22-33 Low Speed [Hz]
22-34 Low Speed Power [kW]
22-35 Low Speed Power [HP]
22-36 High Speed [RPM]
22-37 High Speed [Hz] 22-38 High Speed Power [kW]
22-39 High Speed Power [HP]
22-4* Sleep Mode 22-40 Minimum Run Time
22-41 Minimum Sleep Time
22-42 Wake-up Speed [RPM]
22-43 Wake-up Speed [Hz] 22-44 Wake-up Ref./FB Dierence
22-45 Setpoint Boost 22-46 Maximum Boost Time 22-5* End of Curve 22-50 End of Curve Function 22-51 End of Curve Delay
22-52 End of Curve Tolerance
22-6* Broken Belt Detection 22-60 Broken Belt Function
22-61 Broken Belt Torque
22-62 Broken Belt Delay
22-7* Short Cycle Protection 22-75 Short Cycle Protection
22-76 Interval between Starts
22-77 Minimum Run Time
22-78 Minimum Run Time Override 22-79 Minimum Run Time Override Value
22-8* Flow Compensation 22-80 Flow Compensation 22-81 Square-linear Curve Approximation
22-82 Work Point Calculation 22-83 Speed at No-Flow [RPM] 22-84 Speed at No-Flow [Hz]
22-85 Speed at Design Point [RPM]
22-86 Speed at Design Point [Hz] 22-87 Pressure at No-Flow Speed
22-88 Pressure at Rated Speed
22-89 Flow at Design Point
22-90 Flow at Rated Speed
23-** Time-based Functions 23-0* Timed Actions 23-00 ON Time 23-01 ON Action 23-02 OFF Time 23-03 OFF Action
23-04 Occurrence
23-0* Timed Actions Settings 23-08 Timed Actions Mode 23-09 Timed Actions Reactivation 23-1* Maintenance 23-10 Maintenance Item
23-11 Maintenance Action 23-12 Maintenance Time Base
23-13 Maintenance Time Interval
23-14 Maintenance Date and Time
23-1* Maintenance Reset 23-15 Reset Maintenance Word 23-16 Maintenance Text 23-5* Energy Log 23-50 Energy Log Resolution 23-51 Period Start 23-53 Energy Log 23-54 Reset Energy Log 23-6* Trending 23-60 Trend Variable 23-61 Continuous Bin Data
23-62 Timed Bin Data
23-63 Timed Period Start
23-64 Timed Period Stop
23-65 Minimum Bin Value 23-66 Reset Continuous Bin Data
23-67 Reset Timed Bin Data
23-8* Payback Counter 23-80 Power Reference Factor
23-81 Energy Cost 23-82 Investment 23-83 Energy Savings 23-84 Cost Savings
24-** Appl. Functions 2 24-0* Fire Mode 24-00 Fire Mode Function 24-01 Fire Mode Conguration 24-02 Fire Mode Unit 24-03 Fire Mode Min Reference 24-04 Fire Mode Max Reference 24-05 Fire Mode Preset Reference 24-06 Fire Mode Reference Source
24-07 Fire Mode Feedback Source
24-09 Fire Mode Alarm Handling
24-1* Drive Bypass 24-10 Drive Bypass Function
24-11 Drive Bypass Delay Time
24-9* Multi-Motor Funct. 24-90 Missing Motor Function
24-91 Missing Motor Coecient 1
24-92 Missing Motor Coecient 2
24-93 Missing Motor Coecient 3 24-94 Missing Motor Coecient 4 24-95 Locked Rotor Function 24-96 Locked Rotor Coecient 1
24-97 Locked Rotor Coecient 2
24-98 Locked Rotor Coecient 3 24-99 Locked Rotor Coecient 4
25-** Cascade Controller 25-0* System Settings 25-00 Cascade Controller 25-02 Motor Start 25-04 Pump Cycling
25-05 Fixed Lead Pump
25-06 Number of Pumps
25-2* Bandwidth Settings
25-20 Staging Bandwidth
25-21 Override Bandwidth 25-22 Fixed Speed Bandwidth
25-23 SBW Staging Delay 25-24 SBW Destaging Delay
25-25 OBW Time 25-26 Destage At No-Flow
25-27 Stage Function 25-28 Stage Function Time 25-29 Destage Function 25-30 Destage Function Time
25-4* Staging Settings 25-40 Ramp Down Delay
25-41 Ramp Up Delay 25-42 Staging Threshold 25-43 Destaging Threshold 25-44 Staging Speed [RPM]
25-45 Staging Speed [Hz]
25-46 Destaging Speed [RPM] 25-47 Destaging Speed [Hz]
25-5* Alternation Settings 25-50 Lead Pump Alternation
25-51 Alternation Event
25-52 Alternation Time Interval
25-53 Alternation Timer Value
25-54 Alternation Predened Time
25-55 Alternate if Load < 50%
25-56 Staging Mode at Alternation
25-58 Run Next Pump Delay 25-59 Run on Mains Delay
25-8* Status 25-80 Cascade Status 25-81 Pump Status 25-82 Lead Pump 25-83 Relay Status 25-84 Pump ON Time 25-85 Relay ON Time
25-86 Reset Relay Counters
25-9* Service 25-90 Pump Interlock 25-91 Manual Alternation 26-** Analog I/O Option 26-0* Analog I/O Mode
26-00 Terminal X42/1 Mode
26-01 Terminal X42/3 Mode
26-02 Terminal X42/5 Mode
26-1* Analog Input X42/1 26-10 Terminal X42/1 Low Voltage
26-11 Terminal X42/1 High Voltage
26-14 Term. X42/1 Low Ref./Feedb. Value
26-15 Term. X42/1 High Ref./Feedb. Value
26-16 Term. X42/1 Filter Time Constant
26-17 Term. X42/1 Live Zero
26-2* Analog Input X42/3 26-20 Terminal X42/3 Low Voltage
26-21 Terminal X42/3 High Voltage
26-24 Term. X42/3 Low Ref./Feedb. Value
26-25 Term. X42/3 High Ref./Feedb. Value
26-26 Term. X42/3 Filter Time Constant
26-27 Term. X42/3 Live Zero
26-3* Analog Input X42/5 26-30 Terminal X42/5 Low Voltage
26-31 Terminal X42/5 High Voltage
26-34 Term. X42/5 Low Ref./Feedb. Value
26-35 Term. X42/5 High Ref./Feedb. Value
26-36 Term. X42/5 Filter Time Constant
26-37 Term. X42/5 Live Zero
26-4* Analog Out X42/7
26-40 Terminal X42/7 Output
26-41 Terminal X42/7 Min. Scale
26-42 Terminal X42/7 Max. Scale 26-43 Terminal X42/7 Bus Control
26-44 Terminal X42/7 Timeout Preset
26-5* Analog Out X42/9
26-50 Terminal X42/9 Output
26-51 Terminal X42/9 Min. Scale
26-52 Terminal X42/9 Max. Scale 26-53 Terminal X42/9 Bus Control
26-54 Terminal X42/9 Timeout Preset
26-6* Analog Out X42/11 26-60 Terminal X42/11 Output
26-61 Terminal X42/11 Min. Scale
26-62 Terminal X42/11 Max. Scale 26-63 Terminal X42/11 Bus Control
26-64 Terminal X42/11 Timeout Preset
30-** Special Features 30-2* Adv. Start Adjust
30-22 Locked Rotor Detection
30-23 Locked Rotor Detection Time [s]
30-5* Unit Conguration 30-50 Heat Sink Fan Mode 31-** Bypass Option 31-00 Bypass Mode 31-01 Bypass Start Time Delay
31-02 Bypass Trip Time Delay
31-03 Test Mode Activation
31-10 Bypass Status Word 31-11 Bypass Running Hours 31-19 Remote Bypass Activation
35-** Sensor Input Option 35-0* Temp. Input Mode
35-00 Term. X48/4 Temperature Unit
35-01 Term. X48/4 Input Type
35-02 Term. X48/7 Temperature Unit 35-03 Term. X48/7 Input Type
35-04 Term. X48/10 Temperature Unit
35-05 Term. X48/10 Input Type
35-06 Temperature Sensor Alarm Function
35-1* Temp. Input X48/4 35-14 Term. X48/4 Filter Time Constant
35-15 Term. X48/4 Temp. Monitor
35-16 Term. X48/4 Low Temp. Limit
35-17 Term. X48/4 High Temp. Limit
35-2* Temp. Input X48/7 35-24 Term. X48/7 Filter Time Constant
35-25 Term. X48/7 Temp. Monitor
35-26 Term. X48/7 Low Temp. Limit
35-27 Term. X48/7 High Temp. Limit
35-3* Temp. Input X48/10 35-34 Term. X48/10 Filter Time Constant
35-35 Term. X48/10 Temp. Monitor
35-36 Term. X48/10 Low Temp. Limit
35-37 Term. X48/10 High Temp. Limit
35-4* Analog Input X48/2 35-42 Term. X48/2 Low Current
35-43 Term. X48/2 High Current
35-44 Term. X48/2 Low Ref./Feedb. Value
35-45 Term. X48/2 High Ref./Feedb. Value
35-46 Term. X48/2 Filter Time Constant
35-47 Term. X48/2 Live Zero
43-** Unit Readouts 43-0* Component Status
43-00 Component Temp.
43-01 Auxiliary Temp.
43-1* Power Card Status 43-10 HS Temp. ph.U
43-11 HS Temp. ph.V 43-12 HS Temp. ph.W 43-13 PC Fan A Speed
43-14 PC Fan B Speed 43-15 PC Fan C Speed 43-2* Fan Pow.Card Status
43-20 FPC Fan A Speed
43-21 FPC Fan B Speed 43-22 FPC Fan C Speed 43-23 FPC Fan D Speed 43-24 FPC Fan E Speed 43-25 FPC Fan F Speed
Appendix VLT® HVAC Drive FC 102
