FC 300 Instruction Manual
Warnings and Alarms
Alarm/Warning code list
No. Description Warning Alarm/Trip Alarm/Trip Lock Parameter
Reference
110Voltslow X
2 Live zero error (X) (X) 6-01
3 No motor (X) 1-80
4 Line phase loss (X) (X) (X) 14-12
5 DC link voltage high X
6 DC link voltage low X
7 DC overvoltage X X
8DCundervoltage X X
9 Inverter overloaded X X
10 Motor E TR overtemperature (X) (X) 1-90
11 Motor thermistor overtemperature (X) (X) 1-90
12 Torque limit X X
13 Overcurrent X X X
14 Ground fault X X X
15 Hardware mis-match X X
16 Short Circuit X X
17 Control word timeout (X) (X) 8-04
25 Brake resistor short-circuited X
26 Brake resistor power limit (X) (X) 2-13
27 Brake chopper short-circuited X X
28 Brake check (X) (X) 2-15
29 Power board overtemp X X X
30 Motor phase U missing (X) (X) (X) 4-58
31 Motor pha se V missing (X) (X) ( X) 4-5 8
32 Motor phase W missing (X) (X) (X) 4-58
33 Soft-charge fault X X
34 Serial communication bus fault X X
38 Internal fault X X
47 24 V supply low X X X
48 1.8 V supply low X X
49 Speed limit X
50 AMA calibration failed X
51 AMA check U
nom
and I
nom
X
52 AMA low I
nom
X
53 AMA motor too big X
54 AMA motor too small X
55 AMA parameter out of range X
56 AMA interrupted by user X
57 AMA timeout X
58 AMA internal fault X X
59 Current limit X
61 Tracking Error (X) (X) 4-30
62 Output Frequency at Maximum Limit X
63 Mechanical Brake Low (X) 2-20
64 Voltage Limit X
65 Control Board Overtemperature X X X
66 Heatsink Temperature Low X
67 Option Configuration has Changed X
68 Safe Stop Activated X
80 Drive Initialized to Default Value X
90 Encoder Loss (X) (X) 17-61
(X) Dependent on parameter
LED indication
Warning yellow
Alarm flashing red
Trip-l ocked yellow and red
61
MG.33.A6.22 - VLT is a registered Danfoss trademark
