[126] SL Time-out 6 SL Time-out 6 [126] The result of SLC timer 6.
[127] SL Time-out 7
SL Time-out 7 [127] The result of SLC timer 7.
[130] Digital input DI18
Digital input DI18 [130] Digital input 18. High = True.
[131] Digital input DI19
Digital input DI19 [131] Digital input 19. High = True.
[132] Digital input DI27
Digital input DI27 [132] Digital input 27. High = True.
[133] Digital input DI29
Digital input DI29 [133] Digital input 29. High = True.
[134] Digital input DI32
Digital input DI32 [134] Digital input 32. High = True.
[135] Digital input DI33
Digital input DI33 [135] Digital input 33. High = True.
[150] SL digital output A
SL digital output A [150] Use the result of the SLC output A.
[151] SL digital output B
SL digital output B [151] Use the result of the SLC output B.
[152] SL digital output C
SL digital output C [152] Use the result of the SLC output C.
[153] SL digital output D
SL digital output D [153] Use the result of the SLC output D.
[154] SL digital output E
SL digital output E [154] Use the result of the SLC output E.
[155] SL digital output F
SL digital output F [155] Use the result of the SLC output F.
[160] Relay 1
Relay 1 [160] Relay 1 is active
[161] Relay 2
Relay 2 [161] Relay 2 is active
[180] Local ref. active
Local ref. active [180] High when par. 3-13 “Reference site” =
[2] Local or when par 3-13 is [0] Linked to hand Auto, at the
same time as the LCP is in Hand on mode.
[181] Remote ref. active
Remote ref. active [181] High when par. 3-13 “Reference site”
= [1] Remote or [0] Linked to hand/auto, while the LCP is in
Auto on mode.
[182] Start command
Start command [182] High when there is an active start com-
mand, and no stop command.
[183] Drive stopped
Drive stopped [183] A stop command ( Jog, Stop, Qstop, Coast)
is issued – and not from the SLC itself.
[185] Drive in hand mode
Drive in hand mode [185] High when the drive is in hand mode.
[186] Drive in auto mode
Drive in auto mode [186] High when the drive is in auto mode.
13-11 Comparator Operator
Array [6]
For par. 13-10 containing values from [0] to [31] the following
is valid:
Select the operator to be used in the comparison.
[0] < Select
< [0] for the result of the evaluation to be TRUE, when
the variable selected in par. 13-10 is smaller than the fixed value
in par. 13-12. The result will be FALSE, if the variable selected
in par. 13-10 is greater than the fixed value in par. 13-12.
