2.8. Parameters: Digital In/Out
2.8.1. 5-** Digital In/Out
Parameter group for configuring the digital input and output.
2.8.2. 5-0* Digital I/O Mode
Parameters for configuring the IO mode. NPN/PNP and setting up IO to Input or Output.
5-00 Digital I/O Mode
Option: Function:
Digital inputs and programmed digital outputs are pre-program-
mable for operation either in PNP or NPN systems.
[0]
*
PNP Action on positive directional pulses (↕). PNP systems are pulled
down to GND.
[1] NPN Action on negative directional pulses (↕). NPN systems are
pulled up to + 24 V, internally in the frequency converter.
NB!
When changing this parameter, a power cycle must be carried out before the pa-
rameter change is active.
This parameter cannot be adjusted while the motor is running.
5-01 Terminal 27 Mode
Option: Function:
[0]
*
Input Defines terminal 27 as a digital input.
[1] Output Defines terminal 27 as a digital output.
This parameter cannot be adjusted while the
motor is running.
5-02 Terminal 29 Mode
Option: Function:
[0]
*
Input Defines terminal 29 as a digital input.
[1] Output Defines terminal 29 as a digital output.
This parameter is available for FC 302 only.
This parameter cannot be adjusted while the motor is running.
2.8.3. 5-1* Digital Inputs
Parameters for configuring the input functions for the input terminals.
The digital inputs are used for selecting various functions in the frequency converter. All digital
inputs can be set to the following functions:
